Plan Description

Welcome home to your Spanish villa! This unique design showcases all kinds of amenities: among them, multiple fireplaces (including one in the deluxe master bathroom), stunning foyers, a "wine cove" with two entrances, and lots of outdoor living space. The house has multiple art niches and decorative fixtures as well as groin, domed, coffered, and barrel-vaulted ceilings which add an authentic character that compliments the traditional Spanish design. A guest apartment above the garage houses visitors in style. Kids will love the fun rooms (including a wet bar) on the second floor.

Full Specs & Features


Depth : 92'

Height : 32' 9"

Width : 102'


First Floor: 4112 sq/ft height 12'

Garage: 927 sq/ft

Second Floor: 2381 sq/ft height 10'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Primary Pitch : 4:12

Roof Framing : Truss

Roof Type : Clay Tile

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block (1st Story)/ Wood – 2x6 (2nd Story)

Bedroom Features


Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Butler's Pantry

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Hobby Rec Room Game Room


Main Floor Laundry

Master Sitting Area

Media Room

Mud Room

Storage Area

Upstairs Laundry

Wine Cellar


Garage Features

Side Entry Garage

Outdoor Spaces



Covered Front Porch

Covered Rear Porch

Outdoor Fireplace

Outdoor Kitchen Grill


Jack & Jill Bath



width 19' 4" x depth 15' 8"


width 12' 8" x depth 16'


927 sq/ft width 24' x depth 41' 4"

Gathering Room:

width 17' x depth 21'

Guest Suite:

width 13' 6" x depth 12'

Kitchen Island:

width 23' x depth 15'


width 14' 4" x depth 15'

Living Room:

width 16' x depth 16'

Master Bedroom:

width 15' 8" x depth 20'


width 10' x depth 10'

Porch Front:

265 sq/ft

Porch Rear:

676 sq/ft

Sitting Area:

width 12' x depth 9' 4"


476 sq/ft width 21' x depth 16' 4"

Suite 1:

width 14' x depth 0"

Suite 2:

width 13' x depth 15' 7"

Suite 3:

width 12' x depth 13' 5"


width 36' 4" x depth 19'

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
Questions? Call 1-877-803-2251

Plan Set

5 Copy Set:
5 printed plan sets mailed to you.
CAD Set:
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Set:
PDF plan sets are best for fast electronic delivery and inexpensive local printing.


Ideal for level lot, single layer concrete poured directly on grade.


Wood 2x6:
Wood 2x6

Additional Options

Right-Reading Reverse:
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
Receive an overlay sheet with suggested placement of lighting fixtures.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
