PLAN 942-16

Photographs may show modified designs.

Save
  • Jump to:
  • All (24)
  • Floor plans (3)
Questions? Get Personalized Help Get Cost-To-Build Report Modify This Plan

Key Specs


Plan Sq Ft

5876
sq ft

Plan Bedrooms

5
Beds

Plan Bathrooms

6.5
Baths

Plan Floors

2
Floors

Plan Garages

3
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$935.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$165.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design
$165.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Subtotal
$4400.00
Best Price Guaranteed*

Also order by phone: 1-877-803-2251

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-877-803-2251
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.


Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 942-16

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Modify This Plan

Plan Description


This craftsman design floor plan is 5876 sq ft and has 5 bedrooms and 6.5 bathrooms.

Full Specs & Features


Dimension

Depth : 74' 2"

Height : 41' 9"

Width : 92' 2"

Area

Basement Living: 1986 sq/ft

Basement Unfinished: 691 sq/ft

First Floor: 2725 sq/ft

Garage: 1084 sq/ft

Second Floor: 1165 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 5:12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stone/Stucco

Framing : Wood - 2x6 Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Guest Suite

Main Floor Master Bedroom

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Butler's Pantry

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Exercise Room

Family Room Keeping Room

Great Room Living Room

Hobby Rec Room Game Room

Loft

Main Floor Laundry

Master Sitting Area

Media Room

Mud Room

Open Floor Plan

Storage Area

Upstairs Laundry

Vaulted / Cathedral Ceilings

Wine Cellar

Garage Features

Front Entry Garage

Outdoor Spaces

Balcony

Courtyard

Covered Front Porch

Covered Rear Porch

Deck

Grill Deck Sundeck

Outdoor Kitchen Grill

Rooms

Bedroom 2:

width 15' 6" x depth 12' 6"

Bedroom 3:

width 12' x depth 13'

Bedroom 4:

width 12' 6" x depth 13'

Bedroom 5:

width 11' 6" x depth 12'

Bedroom 5 Living Area:

width 11' x depth 12'

Breakfast Nook:

width 10' x depth 10'

Dining Room:

width 10' 6" x depth 14'

Exercise Room:

width 22' x depth 17'

Family Room:

width 16' x depth 21'

Foyer:

width 9' 6" x depth 12'

Game Room:

width 10' x depth 13'

Garage:

1084 sq/ft width 41' x depth 26'

Great Room:

width 16' x depth 21'

Home Office:

width 11' 6" x depth 12'

Kitchen:

width 16' x depth 17' 6"

Loft:

width 13' x depth 8'

Master Bedroom:

width 17' x depth 20'

Mechanical:

width 23' x depth 7' 6"

Storage/Future Development:

width 22' 6" x depth 18' 6"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
