Plan Description

This ranch design floor plan is 2771 sq ft and has 4 bedrooms and 4.5 bathrooms.

Floor Plans

Floor Plan - Main Floor

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 50'

Height : 17'

Width : 84'

Area

First Floor: 2771 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 4:12

Exterior Wall Framing

Exterior Wall Finish : Brick

Framing : Wood - 2x6

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Additional Room Features

Family Room Keeping Room

Sunroom

Vaulted / Cathedral Ceilings

Outdoor Spaces

Screened Porch

Wrap Around Porch

Rooms

Bedroom 2:

167 sq/ft width 14' 3" x depth 11' 9"

Bedroom 3:

132 sq/ft width 11' 3" x depth 11' 9"

Dining Room:

156 sq/ft width 12' x depth 13'

Family Room:

204 sq/ft width 16' x depth 12' 9"

Garage:

555 sq/ft width 25' 3" x depth 22'

Guest Bedroom:

213 sq/ft width 14' 3" x depth 15'

Living Room:

228 sq/ft width 15' 9" x depth 14' 6"

Master Suite:

320 sq/ft width 21' x depth 15' 3"

What's Included In This Plan Set

See a sample plan set

Exterior Elevations are scaled (1/4" and 1/8" = 1'-0") drawings of the front, rear, left, and right sides of the home.
Detailed Floor plans of the home accurately dimensioning the positioning of the walls, doors, windows, stairs, and permanent fixtures.
Foundation plan details the foot print of the home. Location and size of load points, stem walls, footings, pony walls, and floor joist.
Roof plans are typically truss planing, truss manufacturer will provide detail diagrams of truss's. In some cases the roof plans may be drawn as stick framed or have stick framing which will call out lumber sizes and spacing.
Cross Sections offer a cut away through the home showing your builder the correlation of building components.
Details indicate minimum CABO/IRC standards for construction of the home.
Electrical plan shows the schematic of the electrical layout. Most electricians want to discuss the options the home owner desires prior to bidding.
Mechanical and Detailed Plumbing plans are not included. These are site specific and are accomplished by those professionals.
All plans are prepared in compliance with the Uniform Building Code (ICBO) or the International Residential Code, a National Standard for residential construction at the time of completion.

Questions? Call 1-877-803-2251

Plan Set

5 Copy Set:
$850.00

5 printed plan sets mailed to you.

PDF Set:
$850.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Foundation

Crawlspace:
$0.00

Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab:
$212.50

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00

Wood 2x6 Exterior Walls

Additional Options

Additional Construction Sets:
$51.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$85.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$33.15

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$85.00

Receive an overlay sheet with suggested placement of lighting fixtures.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
