Master bath with dual sinks and large custom shower is close a huge 9’x7’ walk-in closet. Great Room is large and airy with a tray ceiling and ventless gas fireplace. The great room shares a counter-high snack bar with the open plan kitchen The kitchen & dining area has lots of storage and windows Behind the dining area is access to the large screened porch through a mud area with a built-in bench for storage. The laundry room is attached to the double garage with a covered breezeway. The home may be built with or without the breezeway, garage and screened porch, to save space and money.
Full Specs & Features
Depth : 63' 4"
Height : 0"
Width : 68'
Garage : 528 sq/ft
Main Floor : 1587 sq/ft
Porch : 454 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling Details : 10'6" tray ceiling in great room
Main Ceiling : 9'
Exterior Wall Framing
Exterior Wall Finish : siding
Framing : 2x4
Walk In Closet
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Front Entry Garage
Suited For Corner Lot
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Zero Lot Lines
Covered Front Porch
Economical To Build
Suited For Vacation Home
