PLAN 1017-112

Mediterranean Exterior - Front Elevation Plan #1017-112
Mediterranean Exterior - Front Elevation Plan #1017-112

Select Plan Set Options

What's included?
Additional Construction Sets
$90.00/each
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Subtotal
$800.00
Also order by phone: 1-877-803-2251
Cost-to-Build Estimates
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Questions?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-877-803-2251
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 1017-112

Key Specs


1450
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Plan Description


This Mediterranean house plan has a great layout, and is packed into a small footprint. A stucco exterior with double radius columns compliments the front elevation. Inside you will find a very open floor plan great for entertaining. The great room features a large, coffer ceiling and is opened to the kitchen and dining areas. The master suite has a large walk-in closet and a great view of the outdoor living areas. This house plan is perfect for a narrow lot.

Full Specs & Features


Dimension
Depth : 48' 8"
Height : 21' 11"
Width : 40'
Area
First Floor: 1450 sq/ft
Garage: 441 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Clay Tile
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Block
Bedroom Features
Walk In Closet
Additional Room Features
Great Room Living Room
Rooms

Bedroom 2:

134 sq/ft width 12' x depth 11' 2"

Bedroom 3:

138 sq/ft width 12' x depth 11' 6"

Dining Room:

165 sq/ft width 16' 10" x depth 9' 10"

Garage:

390 sq/ft width 19' 10" x depth 19' 8"

Great Room:

259 sq/ft width 15' x depth 17' 4"

Kitchen:

129 sq/ft width 9' 6" x depth 13' 8"

Master Suite:

176 sq/ft width 12' x depth 14' 8"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
Questions? Call 1-877-803-2251
Plan Set
CAD Set :
$800.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Set :
$800.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set :
$800.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

Foundation

Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00
Block

Additional Options

Additional Construction Sets :
$90.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design :
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design :
$100.00
Receive an overlay sheet with suggested placement of lighting fixtures.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Recently Viewed Home Plans
