Key Specs
5007
sq ft
4
Beds
5.5
Baths
2
Floors
3
Garages
Phone: 1-877-803-2251
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 1019-13
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 109' 8"
Height : 34' 1"
Width : 86' 8"
Area
First Floor: 3927 sq/ft height 12'
Garage: 1040 sq/ft height 12'
Second Floor: 1080 sq/ft height 12'
Roof
Primary Pitch : 9:12
Roof Framing : Truss
Roof Type : Concrete
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Block
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Main Floor Master Bedroom
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Media Room
Outdoor Spaces
Balcony
Courtyard
Covered Front Porch
Covered Rear Porch
Rooms
Attic:
348 sq/ft width 12' x depth 29'
Balcony:
164 sq/ft width 13' x depth 12' 8"
Bedroom 3:
186 sq/ft width 14' 4" x depth 13'
Bedroom 4:
229 sq/ft width 14' 4" x depth 16'
Breakfast:
140 sq/ft width 11' 8" x depth 12'
Covered Porch:
256 sq/ft width 11' 8" x depth 22'
Covered Porch:
287 sq/ft width 22' 8" x depth 12' 8"
Dining Room:
214 sq/ft width 15' x depth 14' 4"
Family Room:
392 sq/ft width 18' 8" x depth 21'
Garage:
927 sq/ft width 23' x depth 40' 4"
Guest Suite:
195 sq/ft width 13' x depth 15'
Kitchen:
242 sq/ft width 18' 2" x depth 13' 4"
Laundry Room:
98 sq/ft width 11' 4" x depth 8' 8"
Library:
160 sq/ft width 13' x depth 12' 4"
Living Room:
255 sq/ft width 15' 8" x depth 16' 4"
Master Suite:
337 sq/ft width 14' 8" x depth 23'
Master Walk-In Closet:
159 sq/ft width 11' 8" x depth 13' 8"
Theatre Room:
231 sq/ft width 17' 4" x depth 13' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$2500.00
$3100.00
Foundation
$0.00
Framing
$0.00
Additional Options
$100.00
$39.00
$200.00
$750.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
