PLAN 17-1020

House Design - Traditional Exterior - Front Elevation Plan #17-1020
House Design - Traditional Exterior - Rear Elevation Plan #17-1020
House Design - Traditional Exterior - Other Elevation Plan #17-1020
House Design - Traditional Exterior - Other Elevation Plan #17-1020

Key Specs


Plan Sq Ft

2742
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

2.5
Baths

Plan Floors

1
Floors

Plan Garages

2
Garages

Select Plan Set Options

What's included?
Additional Construction Sets$67.50/each
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Subtotal
NOW $1215.00
You save $135.00
(10% savings)
Sale ends soon!
Also order by phone: 1-877-803-2251
Cost-to-Build Estimates
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Questions?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-877-803-2251
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 17-1020

Key Specs


Plan Sq Ft

2742
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

2.5
Baths

Plan Floors

1
Floors

Plan Garages

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Plan Description


An arched entry accented with elegant dual columns and flanked by charming dormers meshes cleanly with the smooth stucco and rock exterior of this offering. The sun room demands attention with its elegant French door entries, twin sky lights and quick access to three distinct areas of the home and the back yard. The screened porch is sure to be a hit with the beautiful atrium doors leading to the master suite and adjacent placement next to the kitchen. All ceilings 9 ft Stone step entry to front porch with 8 inch boxed columns and vaulted ceiling Foyer with 12 ft ceiling Bedroom 2/Study with 10 ft ceiling Dining room with 8 inch round columns and 10 ft ceiling Kitchen with 10 ft ceiling and desk area, bar open to Breakfast room with 10 ft ceiling, bay window and access to rear screened porch Great room with 10 ft ceiling, built-in media center and fireplace with French doors to Sun room Sun room accessed from screened porch and Great room with French doors-Bedroom 4 access too Master suite has 10 ft boxed ceiling, atrium doors to screened porch Master bath with his/hers closets, whirlpool tub, glass shower with seat and split vanities Side covered porch similar to front porch from garage Proposed upper bonus area Roof Framing: 2x6 Insulation Exterior Walls: R-13 Ceiling Minimum: R-30 Floor Minimum: R-19 Roof Designed Roof Load: 45-lbs. Psf lbs. psf Roof Pitch - Main: 8:12 Roof Pitch - Front Gable: 12:12 Roof Pitch - Porch: 5:12 Room Dimensions: Master Bath - 16/0 x 16/8 Master Suite - 16/8 x 16/8 Laundry - 12/10 x 5/11 Kitchen - 13/6 x 10/4 Nook - 13/6 x 9/6 Great Room - 21/0 x 17/0 Bedroom 4 - 15/4 x 12/0 Bedroom 3 - 11/6 x 12/0 Bedroom 2 - 11/0 x 13/10 Foyer - 7/4 x 10/11 Dining - 12/6 x 16/2 Garage - 20/4 x 25/6 Covered Side Porch - 16/4 x 8/0 Screened Porch - 13/6 x 15/0 Sun Room 21/0 x 8/8 Front Porch 31/6 x 8/0 (10' ceiling) Bonus Room - 32/9 x 26/10 (8' ceiling)

Full Specs & Features


Dimension
Depth : 59'
Height : 27'
Width : 85'
Area
Bonus : 916 sq/ft
Garage : 519 sq/ft
Main Floor : 2742 sq/ft
Porch : 620 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Exterior Wall Framing
Framing : 2"x4"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Play Flex Room
Sunroom
Unfinished Future Space
Garage Features
Side Entry Garage
Entryway
Friend S Entry
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Screened Porch

What's Included In This Plan Set




  • Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
  • Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
  • Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
  • Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
  • Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
  • Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
  • Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
» See important information before purchasing.
Questions? Call 1-877-803-2251
Plan Set
PDF Set :
$1215.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set :
$1305.00
5 printed plan sets mailed to you.
5 Copy and PDF Set :
$1530.00
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set :
$2430.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Crawlspace:
$0.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.
Basement:
$269.10
Ideal for level lot, lower level of home partially or fully underground.

Framing

Wood 2x4:
$0.00
Wood 2x4
Wood 2x6:
$269.10
Wood 2x6

Additional Options

Right-Reading Reverse :
$179.10
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
$67.50
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design :
$90.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design :
$90.00
Receive an overlay sheet with suggested placement of lighting fixtures.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Browse Similar Plans

Recently Viewed Home Plans

Coupon Codes
