Key Specs
2489
sq ft
3
Beds
2.5
Baths
1
Floors
2
Garages
Phone: 1-877-803-2251
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 429-247
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 62'
Height : 21'
Width : 68' 3"
Area
First Floor: 2489 sq/ft height 10'
Roof
Primary Pitch : 5:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone
Framing : Wood - 2x4
Bedroom Features
Fireplace
Split Bedrooms
Kitchen Features
Breakfast Nook
Additional Room Features
Great Room Living Room
Outdoor Spaces
Courtyard
Rooms
Bedroom 2:
146 sq/ft width 10' 3" x depth 14' 3"
Bedroom 3:
150 sq/ft width 10' 9" x depth 14'
Breakfast Room:
231 sq/ft width 12' x depth 19' 3"
Dining Room:
209 sq/ft width 13' 9" x depth 15' 3"
Garage:
564 sq/ft width 23' 9" x depth 23' 9"
Gathering Room:
336 sq/ft width 21' x depth 16'
Kitchen:
176 sq/ft width 11' x depth 16'
Master Bathroom:
231 sq/ft width 11' x depth 21'
Master Bedroom:
248 sq/ft width 17' 9" x depth 14'
Master Closet:
72 sq/ft width 7' x depth 10' 4"
Utility Room:
56 sq/ft width 6' 4" x depth 9'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$900.00
$1000.00
$1250.00
$1250.00
$800.00
Foundation
$0.00
Framing
$0.00
Additional Options
$65.00
$100.00
$39.00
$100.00
$85.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
