PLAN 120-189
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-877-803-2251
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-877-803-2251
Phone: 1-877-803-2251
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 120-189
Key Specs
2414
sq ft
3
Beds
3
Baths
2
Floors
2
Garages
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Full Specs & Features
Dimension
Depth : 58' 5"
Height : 33' 3"
Width : 88' 6"
Height : 33' 3"
Width : 88' 6"
Area
Bonus: 529 sq/ft
First Floor: 1953 sq/ft
Garage: 761 sq/ft
Second Floor: 461 sq/ft
First Floor: 1953 sq/ft
Garage: 761 sq/ft
Second Floor: 461 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 12:12
Roof Framing : Stick
Roof Load : 20 lbs
Roof Type : Shingle
Secondary Pitch : 2:12
Roof Framing : Stick
Roof Load : 20 lbs
Roof Type : Shingle
Secondary Pitch : 2:12
Exterior Wall Framing
Exterior Wall Finish : R-19
Framing : 2x6
Framing : 2x6
Bedroom Features
Main Floor Master Bedroom
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Play Flex Room
Family Room Keeping Room
Main Floor Laundry
Play Flex Room
Garage Features
Front Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Outdoor Kitchen Grill
Covered Rear Porch
Outdoor Kitchen Grill
Rooms
Bedroom 2:
width 12' x depth 11'
Bedroom 3:
width 12' x depth 11'
Bonus Room:
529 sq/ft width 30' 7" x depth 18' 8"
Covered Front Porch:
662 sq/ft width 53' x depth 10'
Covered Rear Porch:
309 sq/ft width 32' 4" x depth 9' 6"
Dining Room:
width 12' x depth 14'
Family Room:
width 19' 4" x depth 19' 9"
Garage:
761 sq/ft width 30' 5" x depth 25' 5"
Kitchen:
width 12' 11" x depth 19' 9"
Master Closet:
width 10' 9" x depth 14' 8"
Master Suite:
width 15' 3" x depth 17' 6"
Study/ Bedroom 4:
width 12' x depth 11' 8"
Utility Room:
width 9' 10" x depth 9' 4"
