Key Specs
1690
sq ft
4
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-877-803-2251
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-1163
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 42'
Height : 26' 8"
Width : 42'
Area
First Floor: 1079 sq/ft height 8' 1"
Garage: 400 sq/ft
Second Floor: 611 sq/ft height 8' 1"
Ceiling
Ceiling Details : Grt Rm/Foyer 10'
Lower Ceiling : 8'
Main Ceiling : 8'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Stone, Shake, Siding
Framing : 2x6
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Additional Room Features
Great Room Living Room
Main Floor Laundry
Unfinished Future Space
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
width 11' 4" x depth 12'
Bedroom 2 Closet:
width 2' 1" x depth 8' 4"
Bedroom 3:
width 11' 4" x depth 10' 8"
Bedroom 3 Closet:
width 2' 1" x depth 5' 4"
Bedroom 4:
width 11' 6" x depth 12'
Bedroom 4 Closet:
width 2' 1" x depth 8' 4"
Covered Front Porch:
width 8' 2" x depth 4' 8"
Dining Room:
width 9' 6" x depth 12'
Garage:
400 sq/ft width 19' 8" x depth 19' 8"
Great Room:
width 15' x depth 18' 8"
Hall:
width 6' x depth 7'
Hall Bath:
width 5' x depth 8' 4"
Hall Closet:
width 4' 1" x depth 2'
Kitchen:
width 9' 6" x depth 12'
Laundry Room:
width 5' 9" x depth 5' 4"
Master Bath:
width 8' 4" x depth 8' 10"
Master Closet:
width 5' 8" x depth 7' 3"
Powder Room:
width 5' x depth 5'
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$973.00
$1016.00
$1215.00
$1215.00
$1921.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$295.00
$39.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
