PLAN 21-160

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Modify This Plan

Plan Description


This is the attractive courtyard house that pays attention to our current lifestyles. As many person's lifestyles have changed we opt to spend our money on an attractive entertainment center, instead of the conventional fireplace. The need for a computer center for all family members is a "must" and is provided for in the home's very versatile "Flex Space". Easy access from the garage to the kitchen and pantry is present in this design. The master suite is spacious with a raised ceiling, large bath with oversized shower, garden tub and a large closet. Well-located utility room. A raised bar complements the well-appointed kitchen. A great value in an open living style home!

Full Specs & Features


Dimension

Depth : 65'

Height : 21' 9"

Width : 50'

Area

First Floor: 1604 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 10:12

Roof Framing : Conventional

Roof Type : Gable

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : 2"x4"

Bedroom Features

Split Bedrooms

Walk In Closet

Kitchen Features

Eating Bar

Additional Room Features

Storage Area

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 2:

128 sq/ft width 11' 4" x depth 11' 4"

Bedroom 3:

130 sq/ft width 11' 4" x depth 11' 6"

Eating:

100 sq/ft width 8' 10" x depth 11' 4"

Garage:

475 sq/ft width 20' 10" x depth 22' 10"

Kitchen:

147 sq/ft width 11' 10" x depth 12' 6"

Living Room:

248 sq/ft width 16' x depth 15' 6"

Master Bedroom:

181 sq/ft width 12' 6" x depth 14' 6"

What's Included In This Plan Set


  • Cover Sheet: Showing architectural rendering of residence
