Half timbers and stucco, in combination with the elaborate two-story facade, create a fairytale attitude on this Tudor adaptation. The covered porch opens to the sunny great room with a corner fireplace situated between a window wall and French doors that lead out to the covered porch. Columns and archways keep the first floor open and airy. The dining rooms sits opposite the elegant staircase with the U-shaped kitchen residing on the right along with a half-bath and the utility room. Upstairs, the master bedrooms boasts a corner fireplace hearth, a sitting area and an adjoining private bath. Bedroom 2, on the right, enjoys a private bath as well.
131 sq/ft width 10' 9" x depth 12' 3"
107 sq/ft width 10' 3" x depth 10' 6"
205 sq/ft width 13' 6" x depth 15' 3"
109 sq/ft width 9' 9" x depth 11' 3"
49 sq/ft width 7' 4" x depth 6' 9"
112 sq/ft width 10' 9" x depth 10' 6"
212 sq/ft width 13' 6" x depth 15' 9"
17 sq/ft width 7' 6" x depth 2' 4"
All plans are drawn at ¼” scale or larger and include :
|5 Copy Set
|5 printed plan sets mailed to you.|
|8 Copy Set
|8 printed plan sets mailed to you.|
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.|
|One printed set for bidding purposes only. Not a legal building set for construction.|
|Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.|
|Choose this option to reverse your plans and to have the text and dimensions readable.|
|Additional Construction Sets
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design
|Receive an overlay sheet with suggested placement of audio and video components.|
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Mirror Reversed Sets
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
