PLAN 42-473
Key Specs
1299
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-803-2251
See our Terms & Conditions and Privacy Policy.
PLAN 42-473
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.Plan Description
Full Specs & Features
Height : 20'
Width : 50'
Garage: 461 sq/ft
Patio: 185 sq/ft
Porch: 103 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Split Bedrooms
Kitchenette Wet Bar
Main Floor Laundry
Open Floor Plan
Covered Front Porch
Covered Rear Porch
3rd BR Closet:
14 sq/ft width 2' x depth 7'
Bedroom 2:
100 sq/ft width 10' x depth 10'
Bedroom 2 Closet:
15 sq/ft width 2' 6" x depth 6'
Bedroom 3:
120 sq/ft width 10' x depth 12'
Bedroom 3 Closet:
15 sq/ft width 2' 6" x depth 6'
Breakfast Room:
90 sq/ft width 9' x depth 10'
Foyer:
49 sq/ft width 7' x depth 7'
Garage:
370 sq/ft width 18' 6" x depth 20'
Garage Storage:
60 sq/ft width 4' x depth 15'
Gathering Room:
238 sq/ft width 14' x depth 17'
Hall Bathroom:
45 sq/ft width 5' x depth 9'
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
85 sq/ft width 8' 6" x depth 10'
Master Bathroom:
156 sq/ft width 10' x depth 15' 8"
Master Bedroom:
168 sq/ft width 12' x depth 14'
Master Closet:
156 sq/ft width 10' x depth 15' 8"
Porch - Front:
108 sq/ft width 6' x depth 18'
Porch - Rear:
141 sq/ft width 8' x depth 17' 8"
Utility Room:
31 sq/ft width 5' 4" x depth 6'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| 5 Copy Set : $750.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $800.00 |
8 printed plan sets mailed to you. |
| PDF Set : $800.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Single Set : $700.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
Additional Options
| Right-Reading Reverse : $175.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
